The MicPlexer 2 is a multi-coupler for Zaxcom ENG receivers with a tuneable filter. Includes a long shaft power connector.
Features:
- NOTIFICATION
MicPlexer 2’s smart LED’s tell you when there’s too much RF signal overloading your wireless and interfering with performance. - AMPLIFICATION
MicPlexer 2 provides an additional 6 dB of gain on every antenna output. - FILTRATION
Improve your wireless performance by removing unwanted RF from your work space, choose from seven pre-set frequency blocks (20 – 26) or create your own 35 MHz window in one of the two user-assignable positions.
| FREQUENCY TUNING RANGE | 512-702 MHZ (35 MHZ BAND, USER SELECTABLE) |
| TUNED PASS BAND | 35 MHZ |
| ATTENUATION +/- 25 MHZ | 12.5 DB |
| ATTENUATION +/- 50 MHZ | 35 DB |
| ATTENUATION +/- 75 MHZ | 51 DB |
| RF GAIN | 6 DB |
| RF CHANNELS | 2 |
| CHANNEL CROSS-TALK | LESS THAN 40 DB |
| AMPLIFIER NOISE FIGURE | .35 DB |
| OIP3 DISTORTION | +37 DB |
| POWER REQUIREMENT | 8 – 18 VDC @ 100 MA |
| SIZE | 1.25″ X 3.25″ D 4.75″ |
| WEIGHT | 8 OUNCES |
